On Delay Timer H3D-S Anly

H3D-S On Delay Timer 10Min 220VAC Din Rail Mount Anly

10Minutes On-Delay Timer 250VAC 5A

Make / Brand: Anly Electronics

Country of Origin: Taiwan

Download Catalogue

Category: Multifunction Timers Tag: On Delay Timer

Description

Description

Function: On Delay Timer
Operating Voltage: AC 200-240V
Allowable Operating Voltage Range: 90-110% of rated operating voltage
Rated Frequency: 50/60Hz
Contact Rating: 250VAC 5A (resistive load)
Reset Time: MAX 0.1s
Power Consumption: Approx. 7VA
Time Range: 10 Minutes
Output Contact: 1C
Standards: UL Listed, CE Certified
Dimension: (H)71.2mm x (W)17.5mm x (D)60mm
