Description

• 14 Pin Relay Timer – Analog Type
• Operating Voltage: AC/DC 100V – 240V, 12 – 2VAC/DC
• Time Range: 1s / 10s / 1m / 10m / 1h / 10h / 60h / 600h
• Functions: On-Delay & Flicker
• Other operating voltages available on request
• Allowable Operating Voltage Range: 85-100% of rated operating voltage
• Rated Frequency: 50/60Hz
• Contact Rating: 250VAC 5A (resistive load)
• Reset Time: MAX 0.2s
• Power Consumption: Approx. 2.5VA
• Output Contact: 4C
• Number of Pin: 14 Pin – Straight Type
• Dimension: (H)28.5mm x (W)22.3mm x (D)52mm
• Standard: CE Certified
• Weight: 45g
• Application: Ideal for Industrial Use.
