Description
- Overview
- Front Panel 53 x 28 mm
- Integral locking spring
- With universal connections
- Touch proof connections to VBG4
- Mounting aperture 50 x 25 mm
- Technical Data
| Supply voltages (Please state when ordering) |
230 V, 50 Hz (Standard) alt. 115 V, 50 Hz alt. 24 V, 50 Hz |
| Other voltage versions | on request |
| Special frequency | 60 Hz |
| Voltage tolerance | ±15% |
| Power consumption (real power) | 0,11 W |
| Counter capacity | 99.999 h. |
| Accuracy of reading | 0,01 h. |
| Numeral height | 4,4 mm |
| Numeral colour | white, decimal figures red |
| Operation indicator | fast-running wheel |
| Permitted ambient temperature | –15°…+50°C |
| Housing | self-extinguishing thermoplastic |
| Mounting | Panel |
| Type of connection | Universal: Screw, soldered and 6.3 x 0.8 mm AMP plug-type connections |
| Type of protection (DIN EN 60529) | Front IP 65 |
| Class of protection | II when fitted in accordance with regulations |
