Description
- Operating Voltage: AC 110-220V 50/60 Hz
- Contact Rating: 250VAC 5A (Resistive Load)
- Reset Time: Max 0.2s
- Power Consumption: Approx. 2VA
- Output Contact: 1C
- Timer Range: 6S / 60S / 6M / 60M
- Number of Pin: 8 Pin – Round
- Mounting: Surface Mount
- Dimension: (H)70mm x (W)49mm x (D)92mm
- Weight: 220g
