On Delay Timer 24-240VAC/DC 0.1s-240H SPTAON1-A1 Sparta

On Delay Timer 24-240VAC/DC 0.1s-240H – Din Rail Type

Make: Sparta

Country of Origin: China



Download Catalogue

Category: Tag:

Description

  • On Delay Timer/Power On-delay
  • Time Range: 0.1S-240h (0.1 seconds – 240 hours) (Adjustable)
  • Operating Voltage: AC/DC 24-240V (50-60Hz)
  • Output Configuration: One set of delay
  • Delay Accuracy: Basic error <1%, Mechanical error <10%, Repeat error <0.5%, Voltage jump error <1%
  • Reset Time: <500ms
  • Mechanical Life: 1×10^5 (Resistive load, room temperature, 1s on & 9s off)
  • Output Contact Capacity: AC/DC24-240V Power supply 10/16A (AC1-Resistive)
  • Environment: Working temperature: -10-55℃ Relative humidity: ≤85% Altitude: ≤2000 meters Storage temperature: -20-75℃, no rain, snow, salt fog and corrosive
  • Protection: IP20
  • Installation Method: 35mm Din Rail Type
  • Model: SPTAON1-A1
  • Make: Sparta
  • Origin: China
