Description
- Class: EN60335 for correct connection only
- Burden: 0.5W
- Auxiliary Power Supply: from 220 to 240V ± 10% – Frequency 50 Hz
- Precision: ±3sec/day at 22°C
- Temperature: working 0°C ÷ +50°C / storage -25°C ÷ +70°C
- Movement: Quartz
- Back-up Time: 100 h
- Minimum Setting Interval: 15 min
- Terminal Wires: 2×2,5 mm2
- Protection Degree: IP20 – Sealable front cover
- Switching Contact: 16(4)A 250V AC
- Operation: Move the pins to the right (Off) or the left(On), as per the neaded
times of connection on which the contact 1-2 will be closed.
